siemens 6GK5005-0BA00-1AB2 unmanaged Industrial Ethernet Switch

This Siemens 6GK50050BA001AB2 SCALANCE X-100 series Unmanaged Industrial Ethernet Switch is

designed to build reliable, maintenance-free network connections in harsh industrial environments.

It solves the core pain points of frequent network interruptions, equipment damage, and data loss

caused by vibration, dust extreme temperatures, and electromagnetic interference when commercial

networking devices are used in factories. With its rugged metal housing, wide operating temperature

range, and flexible installation options, it ensures your production data is transmitted stably even

under the most demanding conditions.

A.Primary Application Fields:

1. Automotive Production Lines: Connects robot controllers, welding controllers, and vision systems to

ensure production cycles are unaffected by network fluctuations.

2. Packaging and Logistics Lines: Provides stable connections for barcode scanners, conveyor con-

trollers, and PLCs in dusty and vibrating environments, ensuring sorting accuracy and efficiency.

3. Water Treatment and Energy Facilities: Deployed in outdoor cabinets or humid environments to

connect remote I/O stations, flow meters, pumps, and valves, enabling 24/7 uninterrupted monitoring.

4. Machine Tools and Equipment Internals: Acts as a compact network hub inside machinery,

connecting drives, HMIs, and master controllers to build an integrated equipment network.

B.Comparison & Advantages

A. Core Differences vs. Commercial Office Switches

Unlike ordinary commercial switches, the SCALANCE X-100 is engineered as a "network fortress" for

industrial environments. While commercial switches typically operate in clean office settings between

0-40°C, our industrial switch works reliably in extreme temperatures from -40°C to 70°C and with-

stands strong vibrations and electro magnetic interference common on production floors. Commercial

devices often use plastic casings and fan cooling, making them prone to dust accumulation and failure.

In contrast, the X-100 features a fanless, all-metal design with better sealing for longer service life. Choo-

sing an industrial switch means investing not just in a network device, but in the continuity of your

production line.

B. Positioning and Advantages Within the Series

Within the Siemens SCALANCE X family, the X-100 series stands out for its excellent cost-performance

ratio and superior ruggedness. Compared to more basic models (e.g., 6GK5005-0BA00-1AA3 ), the

X-100 offers a wider industrial temperature range. Compared to more advanced managed switches,

the X-100 eliminates complex configuration needs—it's plug-and-play, making it the optimal choice

for building small, stable, maintenance- free network segments. If you don't require advanced features

like VLAN or ring redundancy and simply need a reliable network connection point that "never goes

down," the X-100 is the solution designed for you.

C. How to Identify a Reliable, High-Quality Siemens PLC Supplier

A trustworthy supplier proactively transparentizes all details. First, we provide multi-angle, high-

resolution photos of the actual product—including the housing, ports, and a close-up of the label

(clearly showing the order number 6GK5 005-0BA00-1AB2 )—rather than using only official website

images. Second, we clearly mark inventory status and are willing to provide stock proof. Finally, we

offer complete technical support and warranty services (12-month warranty) and can provide formal

procurement channel documentation, ensuring every device you receive is genuine and original.

D. Is this 6GK5005-0BA00-1AB2 brand new and original? Is it in stock?

We guarantee that all Siemens PLC products we sell are 100% brand new and original. This model is a

common stock item and is currently available for immediate shipment.

E. What are the physical dimensions and weight of the product? What installation methods are supported?

The switch has a compact size of approximately 87 x 45 x 100 mm (W x H x D) and weighs about 0.24

kg . It supports standard DIN rail mounting (the most common method in factory control cabinets)

and can also be wall-mounted using the included kit. Its high installation flexibility allows for easy

integration into any cabinet or piece of equipment.

F. It is "unmanaged." What does that mean exactly? Do I need to configure it?

"Unmanaged" means it is a plug-and-play device. No software configuration or IP address setting is

required— simply connect the power and Ethernet cables, and it begins working automatically. This

greatly simplifies de ployment and maintenance, making it perfectly suited for basic network

connection scenarios that do not require network segmentation or advanced traffic management.

G. What is the protection rating of this switch? Can it be used in dusty or damp environments?

Its protection rating is IP30. This means it effectively prevents the ingress of solid foreign objects larger

than 2.5mm in diameter (dust-protected) but is not waterproof. Therefore, it is well-suited for dusty

industrial indoor environments (e.g., workshops) but not suitable for direct exposure to rain or water

splashing. For damp areas, it must be installed inside a control cabinet with a higher protection rating.

H. What is the specific operating temperature range? My workshop gets very hot in summer and has no heating in winter. Can it work there?

This is precisely its strength. Its operating temperature range is -40°C to +70°C. Whether in a swelte-

ring summer workshop or an unheated warehouse or outdoor cabinet in winter, it operates stably,

ensuring your network runs reliably year-round.

I. Does it have fiber optic ports? What communication standards does it support?

This specific model ( 6GK5005-0BA00-1AB2 ) provides 5 x 10/100 Mbps RJ45 copper ports and does not

support fiber optic ports. It fully complies with the IEEE 802.3 (Ethernet) and IEEE 802.3u (Fast Ethernet)

standards and features store-and-forward switching and auto-negotiation/Auto-MDI(X) capabilities essential

for industrial networks, ensuring broad compatibility.

J. How can I verify the product I receive is genuine?

1. Visual Inspection: Genuine modules feature excellent craftsmanship, clear printing, uniform coloring, and tight-fitting connectors.

2. Label Verification: Check that the order number ( 6GK5005-0BA00-1AB2 ) and serial number (S/N) on the module label are clear and unique.

3. Functional Test: Connect using official Siemens software; it should correctly read the module type, serial number, and firmware information.

4. Official Channels: If in doubt, consult Siemens  directly using your purchase proof and product serial number.
